MATRIX 210™ REFERENCE MANUAL
38
3
64
39
[1.54]
[2.52]
2
[0.08]
90°
19
[0.75]
12.5
[0.49]
25
[0.98]
19
[0.75]
60°
30°
12.5
[0.49]
25
[0.98]
60°
30°
Ø 6.2 n°3
n°4 SLOT 3.1
Figure 29 - ST-336 Mounting Bracket Overall Dimensions
38
22
[0.87]
[1.50]
2
[0.08]
10
[0.39]
30°
60°
60°
30°
n°4 SLOT 3.1
Ø 6.2 n°2
10
[0.39]
18.5
[0.73]
18.5
[0.73]
37
[1.46]
Figure 30 - ST-337 Mounting Bracket Overall Dimensions
mm
[in]
