25-PIN CABLE ELECTRICAL CONNECTIONS
75
5
Matrix 210™
EXTERNAL TRIGGER
Vext 30 Vdc max.
18
19
Signal
V
V
CC
~
~
+
-
I1A
I1B
Figure 80 - NPN External Trigger Using External Power
Pin
Name
Function
9
Vdc
Power Supply input voltage +
6
I2A
Input 2 A (polarity insensitive)
10
I2B
Input 2 B (polarity insensitive)
7
GND
Power Supply input voltage -
INPUT 2 CONNECTIONS USING MATRIX 210™ POWER
INPUT DEVICE
Matrix 210™
6
10
9
7
Ground
V
Signal
V
CC
~
~
+
-
Vdc
GND
I2A
I2B
Figure 81 - PNP Input 2 Using Matrix 210™ Power
INPUT DEVICE
Matrix 210™
Signal
6
10
9
7
Ground
V
V
CC
~
~
+
-
Vdc
GND
I2A
I2B
Figure 82 - NPN Input 2 Using Matrix 210™ Power
