Datalogic PowerScan M8300 Readers User Manual

PowerScan™ M8300 Configuration
10 PowerScan™ M8300
END of procedure. YOUR READER IS NOW READY TO READ CODES.
7.
Read the Bind code to pair the PowerScan
™
M8300 to the BC-80X0 cradle.
The reader is dedicated to the cradle. Any previously bound reader will be
excluded.
To connect several readers to the same cradle see the following section "Using
Multiple Readers with Same Cradle".
Bind
Ì$+RN0$-IÎ
The green LED on the PowerScan
™
M8300 will blink: the reader is ready to be
positioned onto the cradle.
8. Firmly position the reader onto the cradle within 10 seconds, a beep will be
emitted, signaling that the BC-80X0 cradle has been paired to the PowerScan
™
M8300, and the green LED on the reader will go off.
9. Configure the BC-80X0 cradle, refer to the “BC-80X0 Quick Reference”.
Green LED

Datalogic PowerScan M8300 Readers Specifications

General

Scanner Type	Laser
Sealing	IP65
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Type	Handheld
IP Rating	IP65
Communication Range	Up to 100 m / 328 ft
Battery Type	Lithium-Ion
Drop Resistance	2.0 m / 6.6 ft onto concrete
Connectivity	Bluetooth, USB
Radio Frequency System	Datalogic STAR Cordless System
Decode Capability	1D / Linear Codes
Interface	RS-232 / USB / Keyboard Wedge
Scan Rate	35 +/- 5 scans/sec
Supported Barcodes	All standard 1D codes including GS1 DataBar
Storage Temperature	-30°C to 70°C
Humidity	5 - 95% (Non-condensing)
Drop Specification	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
