Datalogic PowerScan M8300 Readers User Manual

Charging the Batteries
4PowerScan™ M8300
CHARGING THE BATTERIES
Once the BC-80X0/C-8000 is powered, you can charge the reader's batteries.
Place the PowerScan
™
M8300 into the BC-80X0 cradle or the C-8000 battery charger.
The "Reader" LED on the cradle/battery charger turns red.
The battery is completely charged when the "Reader" LED on the cradle/battery
charger turns green.
To change the batteries, unscrew the retaining screw and extract the battery pack
from the reader handle. Then, insert the new battery pack into the reader handle and
tighten the screw. (See the following figures).
Figure 1 – Changing the Batteries
Before using the Battery, read “Battery Safety” in the following section.
Datalogic recommends annual replacement of rechargeable battery packs
to ensure maximum performance.
1
2

Datalogic PowerScan M8300 Readers Specifications

General

Scanner Type	Laser
Sealing	IP65
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Type	Handheld
IP Rating	IP65
Communication Range	Up to 100 m / 328 ft
Battery Type	Lithium-Ion
Drop Resistance	2.0 m / 6.6 ft onto concrete
Connectivity	Bluetooth, USB
Radio Frequency System	Datalogic STAR Cordless System
Decode Capability	1D / Linear Codes
Interface	RS-232 / USB / Keyboard Wedge
Scan Rate	35 +/- 5 scans/sec
Supported Barcodes	All standard 1D codes including GS1 DataBar
Storage Temperature	-30°C to 70°C
Humidity	5 - 95% (Non-condensing)
Drop Specification	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
