PowerScan™ M8300 Configuration
Quick Reference Guide 11
USING MULTIPLE READERS WITH SAME CRADLE
If you want to use several readers associated with the same cradle, you must first Bind
the cradle with one of the readers (see previously described configuration procedure).
Successive readers
can be associated with the same cradle by following the
configuration procedure substituting the Bind command with Join.
END of procedure.
POWERSCAN
™
M8300/STAR-MODEM™ STAND ALONE SETUP
To configure a PowerScan™ M8300 reader to communicate with STAR-Modem™ in
Stand Alone Mode, follow the "PowerScan™ M8300/BC-80X0 Stand Alone Setup"
procedure substituting steps 6 and 7 with those below:
END of procedure. YOUR READER IS NOW READY TO READ CODES.
7. Join
Ì$+RN1$-NÎ
The green LED on the PowerScan
™
M8300 will blink: the reader is ready to be
positioned onto the cradle. Complete step 8.
CAUTION
All readers associated with the same cradle must have different
addresses.
6. STAR-Modem™ Address
ÌRSRÎ
Read the code above and the four-digit address of the STAR-Modem™.
7. Exit and Save Configuration
Ì$-?Î

Datalogic PowerScan M8300 Readers Specifications

General

Scanner Type	Laser
Sealing	IP65
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Type	Handheld
IP Rating	IP65
Communication Range	Up to 100 m / 328 ft
Battery Type	Lithium-Ion
Drop Resistance	2.0 m / 6.6 ft onto concrete
Connectivity	Bluetooth, USB
Radio Frequency System	Datalogic STAR Cordless System
Decode Capability	1D / Linear Codes
Interface	RS-232 / USB / Keyboard Wedge
Scan Rate	35 +/- 5 scans/sec
Supported Barcodes	All standard 1D codes including GS1 DataBar
Storage Temperature	-30°C to 70°C
Humidity	5 - 95% (Non-condensing)
Drop Specification	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
