Datalogic PowerScan M8300 Readers User Manual

PowerScan™ M8300 Configuration
Quick Reference Guide 9
POWERSCAN
™
M8300/BC-80X0 STAND ALONE SETUP
When the BC-80X0 cradle is connected and powered, configure the PowerScan
™
M8300 by reading the following codes in the given sequence and follow the
instructions.
Note: for the numeric code selection of steps 3, 4, and 5 use the table at the end
of this Quick Reference.
1.
Restore PowerScan
™
M8300 Default
Ì$+$*oÎ
2. Enter Configuration
Ì$+;Î
3. Set Date
ÌIA%Î
+
six digits for Day, Month and Year (DDMMYY).
4. Set Time
ÌIB'Î
+
four digits for Hours and Minutes (HHMM).
5. Set Radio Address
ÌRA0RFHÎ
+
four digits for the PowerScan
™
M8300 Address
(from 0000 to 1999).
All readers used in the same area must have different addresses.
6. Exit and Save Configuration
Ì$-?Î

Datalogic PowerScan M8300 Readers Specifications

General

Scanner Type	Laser
Sealing	IP65
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Type	Handheld
IP Rating	IP65
Communication Range	Up to 100 m / 328 ft
Battery Type	Lithium-Ion
Drop Resistance	2.0 m / 6.6 ft onto concrete
Connectivity	Bluetooth, USB
Radio Frequency System	Datalogic STAR Cordless System
Decode Capability	1D / Linear Codes
Interface	RS-232 / USB / Keyboard Wedge
Scan Rate	35 +/- 5 scans/sec
Supported Barcodes	All standard 1D codes including GS1 DataBar
Storage Temperature	-30°C to 70°C
Humidity	5 - 95% (Non-condensing)
Drop Specification	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
