Datalogic PowerScan M8300 Readers User Manual

PowerScan™ M8300 Configuration
Quick Reference Guide 13
END of procedure. YOUR READER IS NOW READY TO READ CODES.
6. Set Radio Address
ÌRF8Î
+
four digits from the Numeric Table for the PowerScan
™
M8300 Address
(from 0000 to 1999).
All readers used in the same area must have different addresses.
7. Set First STAR-System™ Address
ÌRSRÎ
+
four digits from the Numeric Table in the range 0000 to 1999
8. Set Last STAR-System™ Address
ÌRTTÎ
+
four digits from the Numeric Table in the range 0000 to 1999
Whenever the system is composed of a single base station, the first
and last base station addresses (steps 7 and 8) must have the same
value.
9. Exit and Save Configuration
Ì$-?Î

Datalogic PowerScan M8300 Readers Specifications

General

Scanner Type	Laser
Sealing	IP65
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Type	Handheld
IP Rating	IP65
Communication Range	Up to 100 m / 328 ft
Battery Type	Lithium-Ion
Drop Resistance	2.0 m / 6.6 ft onto concrete
Connectivity	Bluetooth, USB
Radio Frequency System	Datalogic STAR Cordless System
Decode Capability	1D / Linear Codes
Interface	RS-232 / USB / Keyboard Wedge
Scan Rate	35 +/- 5 scans/sec
Supported Barcodes	All standard 1D codes including GS1 DataBar
Storage Temperature	-30°C to 70°C
Humidity	5 - 95% (Non-condensing)
Drop Specification	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
