POWERSCAN® PD8530
110
4.3.4 Mismatch Result
The result of each format may be set in case the match conditions previously
selected are not satisfied.
Once the desired formats have been enabled and a code has been read, the results
corresponding to each format will be concatenated together and transmitted in the
output message. For this reason, it is strongly advised to set the mismatch result for
each format.
Example
Decoded Code: <DATALOGICproduct>
Format definition:
Format Enable/Disable Match Condition Function Mismatch Result
Format 1 Enabled Code having a length
of 16 characters
Select field from
position1 to
position3
No string
Format 2 Disabled / / /
Format 3 Enabled Code having a length
of 25 characters
Substitute string
"ab" with string
"12"
Unformatted read
code
Format 4 Enabled Code having the
substring "AT" in
position 2
Insert string
"789" in position
7
Unformatted read
code
Format 5 Enabled Code belonging to the
PDF417 symbology
Delete string
"DA" and "pr"
Unformatted read
code
O tput message
: <DATDATALOGICproductDATALO789GICproductDATALOGICproduct>
u
Format 1 Format 3 Format 4 Format 5
Define Mismatch Result
Mismatch Result
AAPHBAJJCDBDNKDE
DGEINLGHB
AFLFAMLJPMLKOLLPNDLGCBAIIK
DLDLLDLDDLLLLLLDDDLDDLDLDL
1-5 corresponding to the
.
1 = unformatted read code as output.
Read t
AOCLFLHODNGNENEIEPANHOGOCK
AHPNIJAMDKEOFMHMLJAKEFGEIK
AKCBPJCJGIIJCMCFHPJPBJONNK
AEFBJLBGMHPKMJGONHLFIIIHGK
K
he above code and:
1. read a number in
the range
desired format number;
2 0 = empty string as output
