CONFIGURATION USING CODE SYMBOLS
4.1 DEFAULT SETTINGS
Configuration Field Default Setting
RS-232 Communication
Baud Rate 115200
Parity, Data Bits, Stop Bits No parity; 8 Data bits; 1 Stop bit
Handshake None
ACK/NACK Protocol None
FIFO Enabled
Intercharacter Delay 0
Intercode Delay 0
RX Timeout 10 seconds
Serial Trigger Lock Disabled
Serial Trigger Lock Disable Character NUL
Serial Trigger Lock Enable Character NUL
USB COM Emulation
Handshake None
ACK/NACK Protocol None
FIFO Enabled
Intercharacter Delay 0
Intercode Delay 0
RX Timeout 10 seconds
USB Keyboard Emulation
FIFO Enabled
Intercharacter Delay 0
Intercode Delay 0
*Keyboard Nationality USA
*Keyboard Speed Normal
WEDGE-Communication
*Keyboard Nationality USA
CapsLock OFF
CapsLock Auto-Recognition ON
NumLock OFF
Intercharacter Delay 0
Intercode Delay 0
IBM USB Interface DEFAULT SETTINGS
device usage Handheld
The default values of these parameters are set when reading the interface selection.
19
