POWERSCAN® PD8530
14
Make all PC system connections
as shown in Figure 5:
4.
Figure 5 – PC Wedge Connection
5.
Power up your PC.
CAUTION
When not using the PowerScan® PD8530 reader remember to
disconnect the Wedge interface from the PC before disconnecting
the power cord.
NOTE
always necessary to use
cables adopting an external power supply.
While using the PowerScan® PD8530 it is
3.3 USB INTERFACE SELECTION
The PowerScan® PD8530 reader requires the USB interface cable and the AC/DC
he USB ith:
configure your reader with one of the USB interfaces, follow these
uc
Make all the PowerScan® PD8530 rea r
power adapter
to be connected.
T interface is compatible w
Windows 98 (and later) IBM POS for Windows
Mac OS 8.0 (and later) 4690 Operating S
ystem
To install and
instr tions.
de
connections as shown in Figure 6;
1.
