1D Symbologies Enter/Exit Programming Mode

Product Reference Guide

133

I 2 of 5 Set Length 2

This feature specifies one of the bar code lengths for I 2 of 5 Length Control on page 131.

Length 2 is the maximum label length if in Variable Length on page 243 Mode, or the second

fixed length if in Fixed Length on page 243 Mode. The length includes the bar code’s check and

data characters.

The length can be set from 2 to 50 characters. A setting of 0 specifies to ignore this length

(onl

y one fixed length).

Table 8 provides examples for setting Length 2. See page 243 for detailed instructions on set-

ting this feature.

Table 8. I 2 of 5 Length 2 Setting Examples

STEP ACTION EXAMPLES

1 Desired Setting

Ignore This

Length

4 Characters 14 Characters 50 Characters

Pad with leading zeroes to

yield two digits

00 04 14 50

3 Scan ENTER/EXIT PROGRAMMING MODE

4 Scan SELECT I 2 OF 5 LENGTH 2 SETTING

Scan Two Characters From

Appendix D, Keypad

‘0’ and ‘0’ ‘0’ and ‘4’ ‘1’ and ‘4’ ‘5’ AND ‘0’

6 Scan ENTER/EXIT PROGRAMMING MODE

$CI2L2

Select I 2 of 5 Length 2 Setting

Make a mistake? Scan the CANCEL bar code to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

50 = Length 2 is 50 Characters

Datalogic QuickScan QBT24 series User Manual
