RS-232 Interface Enter/Exit Programming Mode

Product Reference Guide

Data Bits

This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII pro-

tocol for sending and receiving data.

$CR2DA00(CR)

7 Data Bits

$CR2DA01(CR)

8 Data Bits

DEFAULT

Stop Bits

Set the number of stop bits to match host device requirements. See page 232 for more infor-

mation on this feature.

DEFAULT

$CR2ST00(CR)

1 Stop Bit

$CR2ST01(CR)

2 Stop Bits
