Standard Cable Pinouts

Product Reference Guide

271

Table 47.

Standard Cable Pinouts — Handheld (QD24XX model) or Base Station (QBT24XX and GM44XX

Star models) Side

Pin RS-232 OEM USB

Keyboard

Wedge

1 RTS (out)

2 D+ CLKIN (KBD side)

3 D- DATAIN (KBD side)

4 GND GND GND GND

5 RX

6 TX

7 VCC VCC VCC VCC

8 IBM_B CLKOUT (PC side)

9 IBM_A DATAOUT (PC side)

10 CTS (in)
