QUICKSCAN™ 2500 AIMING SYSTEM
PRODUCT REFERENCE GUIDE 3
QUICKSCAN™ 2500 AIMING SYSTEM
The QuickScan™ QD2500, QW2500, QBT2500 and QM2500 normally function by cap-
turing and decoding codes. The reader is equipped with an internal Motionix™ motion-
sensing function which activates the aiming system on device motion. The intelligent
aiming system indicates the field of view which should be positioned over the bar code:
QuickScan™ QD/QBT/QM2500
QuickScan
™
QD/QBT/QM2500’s Aiming System
Relative Size and Location of QuickScan
™
QD/QBT/QM2500’s Aiming System Pattern
on 2D Matrix Symbol
Relative Size and Location of QuickScan
™
QD/QBT2500’s Aiming System Pattern on
Linear bar code
