Datalogic QuickScan QBT2500

TECHNICAL SPECIFICATIONS
296 QUICKSCAN™ 2500
COMMON READING CHARACTERISTICS
Table 29 Reading Characteristics QuickScan
™
QD/QBT/QM2500
Table 30 - Reading Characteristics QuickScan
™
QW2500
QUICKSCAN
™
QD2500
DOF - DEPTH OF FIELD (TYPICAL)
A
a. All labels grade A, typical environmental light, 20°C, label inclination 10°
Symbology
DOF range
Code 39
5 mil: 0.5 to 25.0 cm / 0.2 to 9.8 in
10 mil: 0.5 to 38.0 cm / 0.2 to 14.9 in
EAN/UPCA 13 mils: 0.5 to 51.0 cm / 0.2 to 20.1in
PDF417 6.7 mils: 0.5 to 21.0 cm / 0.2 to 8.3 in
Datamatrix 10 mils: 0.5 to 21.5 cm / 0.2 to 8.5 in
Code 128 5 mil: 2 - 21.5 cm / 0.8" - 8.5"
QR Code 20 mils: 0 to 37.0 cm / 0 to 14.6 in
Max Resolution
1D Linear: 0.077 mm / 3 mils;
PDF417: 0.077 mm / 3 mils;
Data Matrix: 0.127 mm / 5 mils;
QR Code: 0.17 mm / 6.7 mils
QUICKSCAN
™
QW2500
DOF - DEPTH OF FIELD (TYPICAL)
A
a. All labels grade A, typical environmental light, 20°C, label inclination 10°
Symbology
DOF range
Code 39
5 mil: 0.5 to 23.0 cm / 0.2 to 9.0 in
10 mil: 0.5 to 37.0 cm / 0.2 to 14.5 in
EAN13/UPCA 13 mils: 1.0 to 40.0 cm / 0.39 to 15.7 in
PDF417 6.7 mils: 0.5 to 13.5 cm / 0.2 to 5.3 in
Datamatrix 10 mils: 1.0 to 15.5 cm / 0.39 to 6.1 in
QR Code 20 mils: 1.0 to 33.0 cm / 0.39 to 12.9 in
Max Resolution
1D Linear: 0.077 mm / 3 mils;
PDF417: 0.127 mm / 5 mils;
Data Matrix: 0.152 mm / 6 mils;
QR Code: 0.17 mm / 6.7 mils
