SETUP
12
QUICKSCAN™ 2500
STAND INSTALLATION
Hands-Free Stand
An accessory is available which holds the QD/QW2500 reader at a convenient angle
(except those with integrated stand), allowing hands free scanning of items.
It can also be used as a holder. The holder “cup” can be positioned in any of the angles
shown in the
Figure 6 on page 13. The QuickScan
™
QD2500 models automatically recog-
nize the insertion and changes its Scan Mode to allow the user to operate in hands-free
mode.
Figure 5.Hands free holder
NOTE: For QuickScan™ QD2500, to use the Stand Autosense™ (STD-AUTO-
QD25-xx) it is mandatory to remove the End-cap. See
"End-Cap Cover" on
page 13
NOTE: For QuickScan™ QW2500, read the following label to change Scan
Mode to allow the user to operate in hands-free mode.
Scan Mode= Stand Mode/Object Detection
