Datalogic Skorpio X3 User Manual

1 SKORPIO™ X3
82
4
4.8.2 Installing DFU on the Host PC
Datalogic Firmware Utility (DFU) provides administrators with a field upgrade
mechanism. You must have Microsoft® ActiveSync (for Windows XP devices) or
Windows Mobile® Device Center (for Windows 7 and Vista devices) already loaded
and running on the host PC to use DFU. Refer to par. 4.7.1 for more information
about Windows Mobile® Device Center.
NOTE
Prior to installing, you must remove any previous versions of DFU
installed on the host PC.
To install the Datalogic Firmware Utility, complete the following steps on the PC:
1. Insert the CD ROM shipped with your device into the PC and click on the link
to install Datalogic Firmware Utility.
OR
Go to the Datalogic Mobile website and download the most current version of
the Datalogic Firmware Utility. Unzip the file, then double-click to run
DFU_Setup.exe.
Click OK to continue once you have removed previous versions of DFU.
2. The Welcome to DFU Setup Program screen opens.
 Please exit all Windows applications before running this installer.
 Click Next to continue the Setup.
3. Follow the onscreen instructions to complete the installation.

Datalogic Skorpio X3 Specifications

General

Display diagonal	3.2 \
Display resolution	240 x 320 pixels
Display number of colors	-
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.624 GHz
GPS (satellite)	No
Operating system installed	Windows Embedded CE 6.0
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Security algorithms	CCX v4
Interface	USB 1.1, RS-232, micro USB
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Battery capacity	3000 mAh
Product color	Black
Keypad number of keys	38

Weight and Dimensions

Depth	156 mm
Width	76 mm
Height	193 mm
Weight	482 g
