The Stop/Play button allows you to stop image monitoring to save a particular
image. The reader continues to run, only the monitored image is stopped.
The Save image button automatically downloads the current image as a jpg
file to the browser’s default Download folder. The default naming syntax is
image_weekday month day year.jpg (i.e. image_Wed Jan 23 2019.jpg)
The options button opens an options panel on the Monitoring window which
allows:
- setting the quality of the image to monitor (higher quality images reduce
fr
amerate)
- showing only positive results (good read), onl
y negative results, or all results
- showing Code List
- showing Web Monitor images per second
- showing x,y Coordinates to the Monitoring
window. The coordinates report
the mouse position over the monitored image (in pixels).
To close the options panel, click on the image area.
SOFTWARE CONFIGURATION
20 STS320
Statistics Page
