H-Class 115
Fault Messages (continued)
Displayed Message Description Possible Solution(s)
TOP OF FORM FAULT
The printer could not find
a TOF mark within the
maximum length setting,
or TOF was encountered
in an unexpected place.
;
When the SENSOR
TYPE is REFLECTIVE,
this indication is
given for Out Of
Stock.
Check the following
possibilities:
• Calibration may be
necessary (see Section
3.4);
• The Media Sensor may need
adjustment (see Section
3.2);
• The Media Guide may need
adjustment (see Section
3.1);
• The Leveling Cam may need
adjustment (see Section
5.4.1);
• The MAXIMUM LABEL
LENGTH may need to be
increased (see Section
4.2.1); or
• The Media Sensor may need
to be cleaned (see Section
5.6.4).
