128 H-Class
Media (continued)
H-8308X Media Dimensional Requirements
[1]
Minimum
Maximum
Designator Description
inches mm inches mm
A Label width 3.00 76 9 228
B Liner width 3.00 76 9 228
C Gap (or notch) between labels
[3]
.08 2 – –
D Label length
[3]
.25 6 – –
E Media thickness .0025 .06 .01 .25
F Notch opening width .08 2 – –
G Media edge to sensor aperture .20 5 2.25 70
H Reflective mark width
[2]
.47 12 9 228
I Distance between reflective marks
[3]
.25 6 – –
J Reflective mark length
[3]
.08 2 – –
K Label repeat distance
[3]
.33 8 – –
[1]
Units of measure are referenced by the direction of label feed.
[2]
The reflective (black) mark must be carbon based, placed on the backside of the stock, and the
reflectance shall be less than 10% at wavelengths of 950 and 640 nm.
[3]
The maximum allowable length of the combined label and gap (or mark) measurement cannot
exceed 99.99 inches.
7.3 Approved Media and Ribbon
Media (and ribbon for thermal transfer) is an important determinant in the throughput,
quality, and performance of the printed product. The following overview is an introduction to
the different types of material that can be used in the printer. For complete information and
advice regarding a specific application, consult a qualified media specialist or a Datamax
Media Representative. Also available is an informative white paper, "A Brief Introduction to
Media," which can be found on our website at www.datamaxcorp.com
Direct Thermal
Consider three important factors when selecting direct thermal stock:
• The abrasive qualities of the material that covers the thermal reactive layer of the
paper;
• The amount of heat required to start the chemical reaction; and,
• The ability of the media to control that chemical reaction.
