Datamax H-4212X User Manual

H-Class 127
Printing
Method: Direct Thermal or (optional) Thermal Transfer
Speed: 2 - 8 IPS (51 – 203 mmps)
Resolution: 300 DPI (12 dots/mm)
Dot Size (nominal): .0027" X .0039" (.07 mm X .10 mm)
Tear Bar: Downward tear
Media
Types: Die-Cut, Notched, Continuous, and Reflective
(Roll or Fanfold)
Internal Capacity: 8-inch (203 mm) Outer Diameter Roll (on a standard 3-inch
core; or, on a 40 mm core with the optional supply hub)
Ribbon Width Range: 3 inches - 9 inches (76 mm – 228 mm)
Ribbon Length: 1968 feet (600 m)
Dimensions: Reference the drawing and table below:
E
J
I
C
K
A
B
D
H
F
G
Side View
Top View

Datamax H-4212X Specifications

General

Print Resolution	203 dpi
Print Technology	Thermal Transfer or Direct Thermal
Print Speed	12 ips
Media Width	1 inch to 4.65 inches
Media Thickness	0.0025 inches to 0.0100 inches
Connectivity	USB, Serial, Ethernet
Max. Print Width	4.09 inches
Maximum Print Width	4.09 inches
Maximum Print Length	99 inches
Label Width Range	1 inch to 4.65 inches
Label Thickness Range	0.0035" - 0.008" (0.09 mm - 0.2 mm)
Power Requirements	100-240 VAC
