16
10) Proceed according to the Scan Position:
10-Mil Position: Carefully tighten the Mounting Adjustment
Screw.
Mounting
Adjustment Screw
5-Mil Position: Carefully tighten the Locking Screw on the right
side of the Scanner.
Locking Screw
