Dataprobe RSS-16 User Manual

RSS_v180808n RSS Series Page 40
8.7.2. AB-D9-R
Conectors: 9 Pin D’Subminiature, Female
Leads Supported: All 25 Pins Switched
Additional Information: Optional Jumper Configuration for
Signal Ground Pin 7 (See Section 8.4.3) J11
8.7.3. AB-D15-R
Conectors: 25 Pin D’Subminiature, Female
Leads Supported: All 15 Pins Switched
Additional Information: Optional Jumper Configuration for
Signal Ground Pin 7 (See Section 8.4.3) J11
8.7.4. AB-2RJ8-R
Conectors: 8 Wire Modular Jack
Leads Supported: All 8 Wires
Additional Information: Two A/B Switches per card. 6 connectors total. Simultaneous switching only.
Support EIA/TIA 568A wiring scheme for up to 1Gbps Ethernet Applications.
8.7.5. AB-2BNC-R
Conectors: BNC Female
Leads Supported: 1 Switched, Shields Unswitched.
Additional Information: For DS-3 and Applications up to 45Mbps.
