8.7.6. AB-M34-R
Conectors: Winchester M34, Female
Leads Supported: 18 Leads Switched, Grounds Hardwired, Unswitched. See Below
Additional Information:
8.7.7. AB-T50-R
Connectors: 50 Pin Amphenol (Telco). Common – Male, A/B - Female
Leads Supported: All 50 Pins Switched.
Additional Information: Optional Jumper Selection for Pins 25 and 50 Hardwired, Non-Switched. Install Jumper
as indicated for Non-Switched.
Pin
Connector A
Connector B
25
JP2
JP1
50
JP3
JP4
Pin
Connectivity
V
Switched
W
Switched
X
Switched
Y
Switched
Z
Not Supported
AA
Switched
BB
Switched
CC
Not Supported
DD
Not Supported
EE
Not Supported
FF
Not Supported
HH
Not Supported
JJ
Not Supported
KK
Not Supported
LL
Not Supported
MM
Not Supported
NN
Not Supported
Pin
Connectivity
A
Hardwired
B
Hardwired
C
Switched
D
Switched
E
Switched
F
Switched
H
Switched
J
Switched
K
Switched
L
Switched
M
Not Supported
N
Not Supported
P
Switched
R
Switched
S
Switched
T
Switched
U
Switched
