Daum electronic 8080 TRS3 - Package Contents and Parts Identification; Included Device Components; Mounting Hardware and Tools Provided

L /2x
M/2x
C/11x
J/3x
K/4x
E/4x
D/7x
B/4x
A /4x
SW6
B/4x
A /4x
SW6
44
G/4x
H/4x
F/4x
8
13
17
N/8x
Footwithcasterroller
totherear.
Insertthefourrecessedheadscrewswith
spacersleeves(1)troughthetwoholesand
tightenthemfirmly.
Pleaserespecttheproper
positioningofthefeet.
PackageContents
Assemblingthefeet
Thedevice:
Mountinghardware:
Tools
Accessories
1x baseframewithdriveunit
1xdashboardstandwithdashboard&Ushapedhandle
2xfeetset
2xOscillatingpoles/rightandleft
2xTophandlewithcoatingandcaps
2xFootrods/rightandleft
2xStepplateswithcorrespondingscrews
2xBearingshaftsfortheoscillatingpoles(rightandleft)
2xBearingshafts/cranklever(rightandleft)
1xDrinkingbottlewithholderandscrews
4xRecessedheadscrewsM8x50(A)
4xSpacersleeves12Øx37.5mm(B)
11 HexagonalheadscrewsM8x20(C)
7 SpringwashersDIN127-8.1(D)
4 WashersDIN90218.4(E)
4 FlatheadscrewsM5x40(F)
4 WashersDIN1255.3(G)
4 HexagonalnutsM5(H)
3 Domenutf.hex.headscrewsM8(J)
4 CurvedspringwashersEt3159(K)
2 Screws3.5x25(L)
2 Footstopper(M)
8 Swiveljointcaps(N)
1 Wrench8mm
1 Wrench13/17mm
1 AllenwrenchSW6
1 PulsesensorEarclip
1 Relaxationsensor
1 Softwareupdatecable
1 Usermanual
ergo_lyps
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
Smallpartsbox
ergo_lyps Packagecontents
Theergo_lypscanbeassembledeasilyandswiftlybytwopersons.
1
1
