Daum electronic 8080 TRS3 - Installing the Step Plates

Installingthebottleholder
Installingthecoversonthejoints
One(1)oneachside
4coversareusedatthe
connectionoftheoscillating
poleswiththefootrods,
that's2oneachside.
One(1)coveroneachsideoftheoscillatingpoles.
48
N/8x
13
17
J/3x
Mountthebottleholdertothe
dashboardcolumnusingthe
suppliedscrews
Atthispointintheassemblyprocessitispossibletotestthemovementoftheellipsetrainerbyhandto
evaluatetheadjustmentofthepartstoone-another.Ifnovisibledefectandnounexpectedfrictionorsqueak
noisesaredetectedthenyoushouldfirmlytightenallswiveljointsandattachmentscrews,includingthoseofthe
hingepins(13mmor17mm),anddoublechecktheirseatingposition.
Onceyouaresurethatallthescrewsarefirmlytightened,
youcanputonthecorrespondingjointcovers.
J/3x
