Daum electronic 8080 TRS3 - Installing the Oscillating Poles; Assembly Steps: Foot Rods and Step Plates; Installing Front and Rear Foot Rods

47
Installingthefootrods(rear)
Installingthestepplates
front
Thefootplatesareattachedwiththetwoflatheadscrews.Theside
retainingwallmustbelocatedtothesideofthedeviceandthelineof
adjustingholesmustpointtothefront.
Screwthefootstopinplace.
C/4x
13
17
K/2x
Fitthecurvedspringwasher
onthehingepin.
Fitthebearingcarrierwiththe
hingepinonthecranklever.Both
hingepinsmustpointtothefront.
Thenattachthembymeansofa
screwwithwasher.Donottighten
thescrewatthismoment.
8
G/4x
H/4x
F/4x
L /2x
M/2x
E/4x
Rear
left
Rear
right
front
Fitthehingepinsinthebearingcarriers,
respecttheL/Rmarkingonthefrontofthe
hingepins.
Right
footrod
R
Watchforthread
direction!!
Left-/L
Right-/R
thread
Hingepin-
cranklever
R
L
