Daum electronic 8080 TRS3 - Assembly Steps: Handles and Poles; Assembling the Handlebars

Installingtheoscillatingpoles
46
Screwthehingepinsontherightandleftsidesof
thedashboardsupportcolumnandtightentheminplace.
Attachtheoscillatingpolewiththe
screwwithwasherandthecurved
springwasherwithouttightening
thematthismoment.
Installingthefootrods(front)
Attachthefootrodstothe
oscillatingpolesbymeansofthe
screws.Donottightenthescrews
atthismoment.
C/2x
K/2x
E/2x
13
17
13
17
C/4x
13
17
D/4x
front
front
rear
leftside
rear
rightside
Warning!Becarefultoinstallthe
oscillatingpolesontherightside
ofthedevice.(seeillustration).
