SimpleMaintenanceandService Activities
,
Miscellaneous
Every500kmofcumulatedrunningdistanceyoushouldcheckwhetherallthescrews
arestillfirmlyset.Tightenthembackasneeded.
Careshouldbetakentoremovesweatfromthedashboardandtheframeafterevery
trainingsessiontoprotectthepaintagainstrust.Rustdamagecausedbysweatisnot
coveredbythewarranty.
Useasoftclothwettedwithwatertocleantheoutersurfaceofthedevice.A lightsoap
solutionmayalsobeusedtowetthecloth.
ProceduretoreplacetheV-belt:
Unplugthepowercablefromthemainpowersupplybeforeopeningthedevice!
Takeparticularcaretoavoiddamagingtheinternalpartsofyourergo_lypswhileyou
areworking.
Themanufacturerwillnotbeliableforanydamagesarisingasaresultofnegligence
whilechangingtheV-belt!
V-beltsarewearablepartsandassucharenotcoveredbythewarranty.
1.
2.
3.
4.
Followthesamesteps(1to4)asdescribedabovein
reversesequencetoinstallthenewV-belt.
Removethefootrodontherightside.Usethewrench(17mm)
toloosenthehingepin.
(Seepage5)
Removethescrews(9units)fasteningthesidecover.
Removethesidecover.
Thedrivingpartsonthecarrierplate/driveunitarenowfreely
accessible.Pressonthebelttensionleveragainstthetension
spring(9h)toreleasetheV-belttension,andthenpullthebelt
fromthepulley(9a).
BeforeinstallingthenewV-belt,youshouldcleanthebelt
slippingsurfacesofalldrivingparts,aswellasthebeltitself,
withalcoholorcleaningpetroltoremovethegrease.
TheV-beltislocatedontherightsideofthedevice
spring
tension
lever
9
9a
9c
9p
9r
9h
9g
