13
4 Auxiliary On/Off (pump, blower, light)
Two pushes of the Auxiliary button cycles the outlet as follows:
Push 1 (Aux 1)
LCD displays “AUX 1 OFF”, button LED off.
Push (On/Off)
The Scroll button can be used to turn the Auxiliary 1 input ON or OFF.
Push 2 (Aux Off
LCD displays “AUX OFF”, button LED off.
Push (On/Off)
The Scroll button can be used to turn the Auxiliary 2 input ON or OFF.
Button LED green if only Auxiliary 1 is on.
Button LED orange if only Auxiliary 2 is on.
Button LED red if both Auxiliary 1 and Auxiliary 2 are on.
Notes:
Notes:
1. If either Auxiliary is left on, this outlet will automatically switch off after 25 minutes.
2. If the heater element is on, running this outlet may cause the heater to load shed and switch off.
If this occurs the heater will come back on approximately 5 seconds after the pump is deselected.
3. The menu will time out automatically after 5 seconds.
5 Spa Power Variable Speed Blower (SPVSB)
The Air Button controls a Spa Power Variable-Speed Blower (if tted). It is used to turn the blower on/
off and select different operating modes.
Four pushes of the air button cycle the blower as follows:
Push 1 (Blower On)
LCD displays “BLOWER ON HIGH”,
Blower on full speed.
Push 2 (Blower Ramping)
LCD displays “BLOWER RAMPING”,
speed oscillating.
Push 3 (Blower Speed)
LCD displays “BLOWER SPEED”, and bar
graph showing actual speed setting, Blower
on adjustable speed (see below)
Push 4 (Blower Off)
LCD displays “BLOWER OFF”, (Default State)
To Next Page
