DAVIS Vantage Vue Quick Reference Guide

9
Press WIND to toggle between:
• Wind Speed • Wind Direction (degrees)
Press 2ND and UNITS to change unit of measure.
There are four different units of measure for wind speed: 0 mph, 0.0 m/s,
0 km/h, 0 knots
On the compass rose:
Current Wind Direction
Dominant Wind Direction — for a ten-minute period within the last
hour. If dominant wind direction varies, up to six arrows (representing
six ten-minute periods) may be shown.
Current wind direction is the same as one of the dominant wind
directions.
Wind

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
