DAVIS Vantage Vue Quick Reference Guide

20
When an alarm is triggered, you will hear an audible
alarm:
• Until conditions change (i.e., they rise above or fall below the alarm
thresholds you have set) or you clear the alarm, if the console is being run
on AC power.
• For two minutes, if the console is running on battery power.
• For one minute, for a time alarm.
And you will see visible alarms:
• The alarm bell icon will blink on and off.
• A message will appear in the Weather Center.
• Press DONE to silence the alarm.
To clear all alarm settings:
Press 2ND then ALARM to enter the alarm mode. Press 2ND then press and
hold ALARM until dashes appear in all the fields. Press DONE to exit the
alarm screen. (To clear a single alarm, see page 22.)
Silence & Clear
Alarms

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
