DAVIS Vantage Vue Quick Reference Guide

6
Setup Mode
• WIND CUP (This option will only display if you have chose VP2 ISS or
WIND in the ACTIVE TRANSMITTERS screen) — Press + or - to
change wind cup option: SMALL, LARGE, or OTHER.
• RAIN COLLECTOR — Used at factory for calibration.
• RAIN SEASON BEGINS — Press + or - to change the month.
• COOLING/HEATING DEGREE DAY BASE — Press < or > to move
between segments. Press + or - to change the value of the flashing
segment. To clear, press 2ND and CLEAR. (Default is “dashed.”)
• COMMENTARY — Press + or - to toggle between the OFF and ON
setting.
• KEY BEEP — Press + or - to toggle between the OFF and ON setting.
Press < or > to change the volume/tone of sound.
• BAUD RATE (Optional, displays with WeatherLink Data logger) —
Press + or - to set the available baud rate values. (Default of 19200 is
fine for most applications.)
To Exit Setup Mode:
Press and hold DONE.

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
