DAVIS Vantage Vue Quick Reference Guide

19
To set an alarm:
1. Press 2
ND
then ALARM to enter Alarm Mode. The alarm bell icon will
appear on the screen. In each field, you will either see the alarm setting
or, if no alarm has been set, a series of dashes.
2. Press a weather variable key, or use +, – , <, or > to move between
weather variables. Except for the time alarm, the arrow icon displays next
to the variable you have selected.
3. Press HI/LOW to switch between high and low alarms. (Note: Not all
alarms are available for all weather variables. See Vantage Vue Console
Manual for details.)
4. Press 2
ND
then SET to enter or change an alarm setting. Use + or – to
change the digit within a field. Use < or > to move to the next field. Press
DONE to accept the alarm setting. Repeat steps 2–4 to set another
alarm, or press DONE again to exit the alarm screen.
Set Alarms

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
