DAVIS Vantage Vue Quick Reference Guide

22
To clear daily, monthly or yearly HIGH/LOW data:
1. Press HI/LOW.
2. Select the variable you wish to clear.
3. Press 2ND then CLEAR, holding CLEAR down until the digits stop
flashing and zeroes or dashes appear in the field.
To clear a single alarm setting:
1. Press 2ND then ALARM.
2. Select the alarm reading you wish to clear.
3. Press 2ND then CLEAR, holding CLEAR down until the digits stop
flashing and dashes appear in the fields.
4. Press DONE to return to the current weather screen.
To Clear All:
1. To clear all highs and lows and all alarms, press WIND until wind speed
appears, then 2ND, then CLEAR, holding CLEAR down for the entire 6-
second countdown until you see CLEARING NOW in the Weather Center.
Clear

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
