DAVIS Vantage Vue Quick Reference Guide

12
Press 2ND to select the second key function.
The second key function is printed above the top keys and below the bottom
keys.
The icon will appear near the time and date. After you press
another key, the icon will disappear. If you wish to select another second key
function, you must press 2ND again.
The icon will also time out and disappear from the screen if you do not press
another key within a few seconds.
Whenever you see “Press 2ND and Another Key:”
Press and release 2ND and then immediately press the other key.
Press 2nd and + or - to:
Change the console’s contrast: lighter (+) or darker (-). (The changes are
subtle and may require several presses.)
2
ND
Second

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
