DAVIS Vantage Vue Quick Reference Guide

14
Evapotranspiration measurements can only be accessed if the Vantage Vue
Console is listening to a Vantage Pro2 Plus ISS or Vantage Pro2 with solar
radiation sensor. If you press 2ND and ET while listening to a Vantage Vue
ISS, the console will not display ET readings and you will hear an error beep.
Press 2ND and ET to toggle between:
•ET Day
• ET Month
• ET Year
Press 2ND and UNITS to change unit of measure.
There are two different units of measure for ET values: (0.00 in, 0.0 mm).
Changing the unit of measure for ET changes RAIN units as well.
(ET) (Optional)
Evapotranspiration

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
