DAVIS | WeatherLink Console User Guide
davisinstruments.com
APPENDIX B: SPECIFICATIONS
Console Operating Temperature +32° to +122° F (0° to +50° C)
Non-Operating (Storage) Temperature -20° to +60° C (-4° to +60° C)
Console Current Draw 2A max
Power Adapter 5 VDC, 2000 mA
Battery Backup Lithium Polymer
Battery Life (no AC power) Less than one day when fully charged
Console Display Type In-Plane Switching LED
Dimensions
Console 8.25” x 6” x 0.75” (210mm x 152mm x 19mm)
Display Area 6.75” X 4.25” (171mm x 107mm)
Weight 1.1 pounds (501 grams)
Wireless Communication Specications and Receive Frequencies:
USA 902 - 928 MHz FHSS
EU 868.0 - 868.6 MHz FHSS
Australia, Brazil 918 - 926 MHz FHSS
New Zealand, Peru 921 - 928 MHz FHSS
India 865 - 867 MHz FHSS
Japan 928.15 - 929.65 MHz FHSS
Taiwan, Pakistan 920 - 925 MHz FHSS
ID codes available 8
Range
Line of Sight up to 1000 feet (300 m)
Through Walls 200 to 400 feet (75 to 120 m)
