DriveRack® 260 User Manual
37
Detailed Parameters
Section 4
Pink Noise On/Off
Turns the pink noise generator on and off.
Noise Level -20 to 20
Adjusts the overall level of the pink noise generator.
4.12 Output
The output section of the DriveRack 260 provides the user with the ability to control output levels of the unit and
adjust phase compensation of loudspeakers within the signal path. The output level control is located in the signal path
before the limiters; this means that the limiter directly affects the output level. The parameters for the Phase/Polarity
Compensation effect are as follows and are user adjustable. Please refer to section A.7 of the Appendix for a complete
output signal routing diagram.
Shift On/Off
This parameter is used to turn the selected output phase parameters on or off. When Shift is off, phase is 0
0
and polarity
is positive (+).
Polarity +/-
This parameter is used to reverse the polarity of the output signal.
Phase 0 to -175 Degrees
This parameter is variable in 5 degree increments and sets the amount of phase shift within the selected output path.
The phase is referenced to the upper frequency of the selected output crossover band.
