The NEXT and PREV
buttons scroll through
the pages of selected module.
<PREV PG NEXT PG>
Subharmonic - -On/Off
Subharmonics % 0-100
24-36Hz Level - 24-36Hz
36-56Hz Level - 36-56Hz
Subharmonic
SUBHARMONIC
From program mode, press the SUBHARMONIC button. Pressing the Data Wheel will select the effect parameter to be edited.
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
2.4 Navigating the Subharmonic Section
The EQ button
toggles through
the EQs used in
each channel of
the selected
program
menu.
PEQ
GEQ
or
To edit the parameters of the EQs used in a selected program, simply use the following procedure. From program mode,
press the EQ button to reach the EQ module to be edited. Successive presses of the EQ button will move through each channel.
Navigate through the Pages of the selected EQ section by depressing "Next Page" or "Prev Page" successively until arriving at the desired Page.
GEQ On/Off
Flatten/Restore
EQ
EQ
Frequency
Gain -12dB to12dB
PEQ On/Off
Flatten/Restore
Bell,HSelf, LShelf, LHShelf,
Band 1 Freq
Gain -12dB to12dB
Q .20 to 16.0
Band 2 Freq
Gain -12dB to12dB
Q .20 to 16.0
Band 3 Freq
Gain -12dB to12dB
Q .20 to 16.0
Successive presses of the Data wheel will select
effect parameters within the currently selected page.
GEQ/PEQ
2.3 Navigating the EQ Section (28-GEQ and PEQ)
Editing Functions
Section 2
DriveRack
™
PA
13
DriveRack™ PA User Manual
