Frequency response
(set to Filter 1)
Fs = 44.1kS/s & CD
Fs = 48kS/s
Fs = 88.2 or 96kS/s
Fs = 176.4 or 192kS/s
Fs = 352.8 or 384kS/s
DSD/64
DSD/128
+/-0.1dB, 10Hz to 20kHz
+/-0.1dB, 10Hz to 20kHz
+/-0.1dB, 10Hz to 20kHz
+/-0.1dB, 10Hz to 20kHz
+/-0.1dB, 10Hz to 20kHz
+/-0.1dB, 10Hz to 20kHz
+/-0.1dB, 10Hz to 20kHz
-3dB @ >38kHz
-3dB @ >67kHz
-3dB @ >100kHz
-3dB @ >90kHz
-3dB @ >100kHz
Residual noise
(6V output setting)
CD playback: Better than –96dB0, 20Hz - 20kHz unweighted.
24-bit data: Better than –113dB0, 20Hz - 20kHz unweighted.
DSD upsampling
Optional 1-bit 2.822 or 3.07MS/s upsampling (set in the menu) to supplement
the multi-stage PCM oversampling.
Spurious responses
Better than –105dB0, 20Hz - 20kHz.
L-R crosstalk
Better than –115dB0, 20Hz - 20kHz.
Output levels
6V, 2V, 0.6V or 0.2V rms on all outputs for a full-scale input, set in the menu.
Balanced outputs
1 stereo pair on 2x 3-pin male XLR connectors (pin 2 = hot, pin 3 = cold).
These outputs are electronically balanced and floating, the signal balance
ratio at 1kHz is better than 40dB. Output impedance is 3Ω, maximum load is
600Ω (a 10kΩ - 100kΩ load is recommended).
Unbalanced outputs
1 stereo pair on 2x RCA Phono connectors. Output impedance is 52Ω,
maximum load is 600Ω (a 10kΩ - 100kΩ load is recommended).
Size and weight
444mm (17.5”) wide x 435mm (17.2”) deep x 151mm (6.0”) high. Allow extra
depth for cable connectors. Allow space for air flow around the unit.
17.4kg (38.3lbs).
Power requirements
Internally set to either 100, 115/120, 220 or 230/240V AC, 49 – 62Hz.
Power consumption: 26W typical, 50W maximum.
Consumes less than 0.5W when powered down from the front panel.
These specifications are subject to change without notice.
