48 Adjusting The Video Monitor
3. Gently rotate the yoke until the display is square and level on the
CRT/yoke/bezel assembly.
CAUTION
Make sure you take up the slack on the CRT clamp before you
tighten the screw. Do not overtighten, or you may crack the
CRT neck.
4. Tighten the screw on the CRT connector clamp.
GSF_1464_89.DG
Figure 4–5 Rotation and Centering Adjustment
