Deif AGC 100 Installation Instructions

* The status relay is the uP watchdog output. This relay is normally energised, and the switch is closed after
power-up. If the uP fails or the power is lost, the relay will de-energise and the switch will open. If the unit fails
to start up at power-up, then the relay switch will remain open. The relay is configurable.
** If terminal 20 is used for emergency stop, please see wiring diagram below.
The relay output functions are configurable via the PC utility software and can, among many other functions,
be configured to cover the following in I/O settings:
● Status OK
● Run coil
● Stop coil
● Stop coil (not activated in start seq.)
● Prepare
● Starter(crank)
● Horn
● GB on
● GB off
● MB on
● MB off
It is possible to choose run coil on one relay and stop coil on another, thus supporting engines with double
systems.
The multi-functional inputs can be configured to cover the following functions:
● RMI sensor input
● 4 to 20 mA input
● Binary input with wire break (switch function)
● Pt1000
Tacho RPM input (MPU) can be configured to cover the following functions:
● Magnetic pickup (2-wire)
● NPN or PNP pickup*
* These RPM inputs require external equipment.
Tacho RPM input with capacitor (W/L) can be configured to cover the following functions:
● Magnetic pickup (2-wire)
● W terminal on charger alternator
● NPN or PNP pickup*
* These RPM inputs require external components.
The generator voltage and current input can be configured to the following:
● Voltage 100 to 25000 V primary
● Current 5 to 9000 A primary
AGC 100 installation instructions
4189340752 UK
Terminals
DEIF A/S Page 10 of 28

Deif AGC 100 Specifications

General

Brand	Deif
Model	AGC 100
Category	Controller
Language	English
