DESIGNER’S HANDBOOK 4189350049C EN Page 102 of 206
8.3.5.3 Local time offset received via XDi-net
XDi indicators that needs local time offset via XDi-net (CAN) must be setup so that “Source input” is changed to
XDi-net:
Change the source input to XDi-net:
The local time offset parameters that XDi-needs, is now received via XDi-net and it is not possible to change any of
the other parameters since it is not relevant (they are greyed out in the menu).
8.3.5.4 Local time offset – manual setup
If the local time offset is not available via NMEA or via XDi-net, it is possible to manually insert a local time offset.
The time offset that can be inserted is relative to UTC time.
The source input for local time offset shall then be changed to Manual:
In manual mode the local “Time offset” parameters: hours and minutes can be setup and are then used to
calculate the local time that may be presented on another XDi-N virtual indicator on the CAN bus.
