DESIGNER’S HANDBOOK 4189350049C EN Page 53 of 206
The following table lists the errors and how they are displayed (can also be used for troubleshooting):
Display pop-up text
Warning
type
Duration
Error causes
Warning
On while error
persists
• Used CAN data is not received before
timeout
• Data from XDi-net or an internal input
converter is not received (for example data
for a digital readout of analogue %
indication)
Warning
On while error
persists
• Data from analogue module in slot 1
input is not received
• data value is outside error/range limits
• AX1 module not mounted in Slot 1
Warning
On while error
persists
• Data from analogue module in slot 2
input is not received
• Data value is outside error/range limits
• AX1 module not mounted in Slot 2
Warning
On while error
persists
DX1 module not mounted in Slot 1
Warning
On while error
persists
DX1 module not mounted in Slot 2
Warning
On while error
persists
NMEA data on a configured NX2 module
mounted in Slot 1 is not received (can also
alternate with Data lost!)
Warning
On while error
persists
NMEA data on a configured NX2 module
mounted in Slot 2 is not received (can also
alternate with Data lost!)
Warning
On while error
persists
Single power supply monitoring only.
The monitored power supply (1 or 2) voltage is
under 18.5 VDC (±1 V) *
Warning
On while error
persists
Monitoring both supply inputs.
Both power supplies voltage is under
18.5 VDC (±1 V)*
Alert
Blinking while error
persists
Power supply 2 voltage is under
18.5 VDC (±1 V)*
Alert
Blinking while error
persists
Power supply 2 voltage is under
18.5 VDC(±1 V)*
* Provided the XDi is still on
Data lost!
AX1 S1 Input Error
AX1 S2 Input Error
DX1 S1 Input Error
DX1 S2 Input Error
NMEA S1 Input Error
NMEA S2 Input Error
Power Low!
Power 1&2 Low!
Power 1 Lost!
Power 2 Lost!
