V0413, 22
Below this line, a table is shown with the bend steps of this prod-
uct. Each line represents one bend step. The first column con-
tains the bend number. For each bend step, the following
properties can be programmed:
Number of the tool which is used for this
product.If the cursor is on the tool icon the
tool selection menu can be selected by
pressing the left arrow key.
Material ID number.
Sheet thickness of this product.
Product width. This value is used for bend-
ing force calculation. The availability of this
parameter is depending on machine set-
tings.
Stock counter: count the number of prod-
ucts.
If programmed to 0, the counter will
increase after each finished product. If pro-
grammed higher than zero, the counter will
count down. When it has reached 0, the
control will stop and the stock counter will
be reset to the programmed value.
Angle of this bend.
Program here the required angle value.
This parameter is available when a tool is
programmed.
