Delfield N8143B-E - Cutout Installation Dimensions

Part Number: 9291458 REV00 12/19 13
Section 2 Installation
Cutout Installation Dimensions
Model Counter Cutout
Dimensions
Control Panel Cutout
Dimensions
8100-EFP Series
8118-EFP 17” x 25”
(43cm x 64cm)
NA
8132-EFP 30.75” x 25”
(78cm x 64cm)
NA
8145-EFP 44.25” x 25”
(112cm x 64cm)
NA
8159-EFP 57.87” x 25”
(147cm x 64cm)
NA
8172-EFP 71.5” x 25”
(182cm x 64cm)
NA
8186-EFP 85” x 25”
(216cm x 64cm)
NA
8100-EF-E Export Series
8118-EF-E 17” x 25”
(43cm x 64cm)
NA
8132-EF-E 30.75” x 25”
(78cm x 64cm)
NA
8145-EF-E 44.25” x 25”
(112cm x 64cm)
NA
8159-EF-E 57.87” x 25”
(147cm x 64cm)
NA
8172-EF-E 71.5” x 25”
(182cm x 64cm)
NA
8186-EF-E 85” x 25”
(216cm x 64cm)
NA
8100-EFNP Series
8148-EFNP 46.88” x 17.25”
(119cm x 44cm)
NA
8169-EFNP 68.5” x 17.25”
(174cm x 44cm)
NA
8191-EFNP 90” x 17.25”
(229cm x 44cm)
NA
8100-EFN-E Export Series
8148-EFN-E 46.88” x 17.25”
(119cm x 44cm)
NA
8169-EFN-E 68.5” x 17.25”
(174cm x 44cm)
NA
8191-EFN-E 90” x 17.25”
(229cm x 44cm)
NA
N8000 Series
N8018
17” x 25”
(43cm x 64cm)
NA
N8030
29.75” x 25”
(76cm x 64cm)
NA
N8043
42.5” x 25”
(108cm x 64cm)
NA
N8056
55.25” x 25”
(140cm x 64cm)
NA
N8069
68” x 25”
(173cm x 64cm)
NA
N8081
80.75” x 25”
(205cm x 64cm)
NA
Model Counter Cutout
Dimensions
Control Panel Cutout
Dimensions
N8000N Series
N8046N
45.75” x 17”
(116cm x 43cm)
NA
N8068N
66.50” x 17”
(169cm x 43cm)
NA
N8000-R Series
N8044-R See drawing on
page 16
NA
N8059-R See drawing on
page 16
NA
N8076-R See drawing on
page 16
NA
N8094-R See drawing on
page 16
NA
N8100BP Series
N8118BP 17” X 25”
(43cm x 64cm)
NA
N8130BP 29.75” x 25”
(76cm x 64cm)
NA
N8143BP 42.50” X 25”
(108cm x 64cm)
NA
N8156BP 55.25” x 25”
(140cm x 64cm)
NA
N8169BP 68” X 25”
(173cm x 64cm)
NA
N8181BP 80.75” x 25”
(205cm x 64cm)
NA
N8100B-E Export Series - R404A
N8118B-E 17” X 25”
(43cm x 64cm)
NA
N8130B-E 29.75” x 25”
(76cm x 64cm)
NA
N8143B-E 42.50” X 25”
(108cm x 64cm)
NA
N8100B-E Export Series - R134A
N8156B-E 55.25” x 25”
(140cm x 64cm)
NA
N8169B-E 68” X 25”
(173cm x 64cm)
NA
N8100-BRP Series
N8144-BRP See drawing on
page 16
NA
N8159-BRP See drawing on
page 16
NA
N8176-BRP See drawing on
page 16
NA
N8194-BRP See drawing on
page 16
NA
