14 Part Number: 9291458 REV00 12/19
Installation Section 2
Model Counter Cutout
Dimensions
Control Panel Cutout
Dimensions
N8100FAP Series
N8131-FAP 30.25” x 25.5”
(77cm x 65cm)
NA
N8144-FAP 43” x 25.5”
109cm x 65cm)
NA
N8157-FAP 55.75” x 25.5”
(142cm x 65cm)
NA
N8169-FAP 68.5” x 25.5”
174cm x 65cm)
NA
N8182-FAP 81.25” x 25.5”
(206cm x 65cm)
NA
N8100NBP Series
N8146NBP 45.75” x 17”
(116cm x 43cm)
NA
N8168NBP 66.5” x 17”
(169cm x 43cm)
NA
N8100NB-E Export Series
N8146NB-E 45.75” x 17”
(116cm x 43cm)
NA
N8168NB-E 66.5” x 17”
(169cm x 43cm)
NA
N8200P Series
N8231P 30.75” x 25"
(78cm x 64cm)
NA
N8245P 44.63” x 25”
(113cm x 64cm)
NA
N8259P 58.50” x 25”
(149cm x 64cm)
NA
N8273P 72.38” x 25”
(184cm x 64cm)
NA
N8287P 86.25” x 25”
(219cm x 64cm)
NA
N8200-E Export Series
N8231-E 30.75” x 25"
(78cm x 64cm)
NA
N8245-E 44.63” x 25”
(113cm x 64cm)
NA
N8259-E 58.50” x 25”
(149cm x 64cm)
NA
N8273-E 72.38” x 25”
(184cm x 64cm)
NA
N8287-E 86.25” x 25”
(219cm x 64cm)
NA
N8200GP Series
N8231GP 30.75” X 25”
(78cm x 64cm)
NA
N8245GP 44.63” x 25”
(113cm x 64cm)
NA
N8259GP 58.5” x 25”
(149cm x 64cm)
NA
N8273GP 72.38” x 25”
(184cm x 64cm)
NA
Model Counter Cutout
Dimensions
Control Panel Cutout
Dimensions
N8200G-E Export Series
N8231G-E 30.75” X 25”
(78cm x 64cm)
NA
N8245G-E 44.63” x 25”
(113cm x 64cm)
NA
N8259G-E 58.5” x 25”
(149cm x 64cm)
NA
N8200-STP Series
N8230-STP 28.60” x 21.10"
(73cm x 54cm)
NA
N8240-STP 38.65” x 28.75”
(98cm x 73cm)
NA
N8256-STP 54.60” x 21.10”
(139cm x 54cm)
NA
N8258-STP 56.60” x 28.75”
(144cm x 73cm)
NA
N8275-STP 74.50" x 28.75"
(189cm x 73cm)
NA
N8600P Series
N8630P 29.75” X 25”
(76cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8643P 42.50” x 25”
(108cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8656P 55.25” x 25”
(140cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8669P 68” x 25”
(173cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8681P 80.75” x 25”
(205cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8700D Series
N8717-D 16.88” X 25”
(43cm x 64cm)
7” x 4.62” x 7”
(18cm x 12cm x 18cm)
N8731-D 30.75” x 25”
(78cm x 64cm)
10.31” x 4.62” x 7”
(26cm x 12cm x 18cm)
N8745-D 44.62” x 25”
(113cm x 64cm)
14.5” x 4.62” x 7”
(37cm x 12cm x 18cm)
N8759-D 58.5” x 25”
(149cm x 64cm)
18.69” x 4.62” x 7”
(47cm x 12cm x 18cm)
N8773-D 72.37” x 25”
(184cm x 64cm)
22.88” x 4.62” x 7”
(58cm x 12cm x 18cm)
N8787-D 86.25” x 25”
(219cm x 64cm)
27” x 4.62” x 7”
(69cm x 12cm x 18cm)
N8700D-E Export Series
N8717-D-E 16.88” X 25”
(43cm x 64cm)
7” x 4.62” x 7”
(18cm x 12cm x 18cm)
N8731-D-E 30.75” x 25”
(78cm x 64cm)
10.31” x 4.62” x 7”
(26cm x 12cm x 18cm)
N8745-D-E 44.62” x 25”
(113cm x 64cm)
14.5” x 4.62” x 7”
(37cm x 12cm x 18cm)
N8759-D-E 58.5” x 25”
(149cm x 64cm)
18.69” x 4.62” x 7”
(47cm x 12cm x 18cm)
N8773-D-E 72.37” x 25”
(184cm x 64cm)
22.88” x 4.62” x 7”
(58cm x 12cm x 18cm)
N8787-D-E 86.25” x 25”
(219cm x 64cm)
27” x 4.62” x 7”
(69cm x 12cm x 18cm)
