Delfield N8143B-E - Page 15

Part Number: 9291458 REV00 12/19 15
Section 2 Installation
Model Counter Cutout
Dimensions
Control Panel Cutout
Dimensions
N8700DESP Series
N8717-DESP 16.87” X 25”
(43cm x 64cm)
5” x 6.88” x 7.50”
(13cm x 17cm x 19cm)
N8731-DESP 30.75” x 25”
(78cm x 64cm)
5” x 11.88” x 7.50”
(13cm x 30cm x 19cm)
N8745-DESP 44.62” x 25”
(113cm x 64cm)
5” x 17.38” x 7.50”
(13cm x 44cm x 19cm)
N8759-DESP 58.50” x 25”
(149cm x 64cm)
5” x 22.88” x 7.50”
(13cm x 58cm x 19cm)
N8773-DESP 72.37” x 25”
(184cm x 64cm)
5” x 28.38” x 7.50”
(13cm x 72cm x 19cm)
N8787-DESP 86.25” x 25”
(219cm x 64cm)
5” x 33.88”x 7.50”
(13cm x 86cm x 19cm)
N8700-D-ESP-E Export Series
N8717-D-ESP-E 16.87” X 25”
(43cm x 64cm)
5” x 6.88” x 7.50”
(13cm x 17cm x 19cm)
N8731-D-ESP-E 30.75” x 25”
(78cm x 64cm)
5” x 11.88” x 7.50”
(13cm x 30cm x 19cm)
N8745-D-ESP-E 44.62” x 25”
(113cm x 64cm)
5” x 17.38” x 7.50”
(13cm x 44cm x 19cm)
N8759-D-ESP-E 58.50” x 25”
(149cm x 64cm)
5” x 22.88” x 7.50”
(13cm x 58cm x 19cm)
N8773-D-ESP-E 72.37” x 25”
(184cm x 64cm)
5” x 28.38” x 7.50”
(13cm x 72cm x 19cm)
N8787-D-ESP-E 86.25” x 25”
(219cm x 64cm)
5” x 33.88”x 7.50”
(13cm x 86cm x 19cm)
N8700N Series
N8746ND 44.62” x 15.0”
(113cm x 38cm)
10.31” x 4.62” x 7”
(26cm x 12cm x 18cm)
N8768N 66.50” x 15.0”
(169cm x 38cm)
14.50” x 4.62” x 7”
(37cm x 12cm x 18cm)
N8768ND 66.50” x 15.0”
(169cm x 38cm)
14.50” x 4.62” x 7”
(37cm x 12cm x 18cm)
N8700-R Series
N8744-R See drawing on
page 16
10.31” x 4.62” x 7”
(26cm x 12cm x 18cm)
N8759-R See drawing on
page 16
14.5” x 4.62” x 7”
(37cm x 12cm x 18cm)
N8776-R See drawing on
page 16
18.69” x 4.62” x 7”
(47cm x 12cm x 18cm)
N8794-R See drawing on
page 16
22.88” x 4.62” x 7”
(58cm x 12cm x 18cm)
N8800 Series
N8831 30.75” X 25”
(78cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8845 44.63” x 25”
(113cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8859 58.5” x 25”
(149cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8873 72.38” x 25”
(184cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8887 86.25” x 25”
(219cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
Model Counter Cutout
Dimensions
Control Panel Cutout
Dimensions
N8800-E Export Series
N8831-E 30.75” X 25”
(78cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8845-E 44.63” x 25”
(113cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8859-E 58.5” x 25”
(149cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8873-E 72.38” x 25”
(184cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
N8887-E 86.25” x 25”
(219cm x 64cm)
12.25” x 4.25” x 7”
(31cm x 11cm x 18cm)
