Dell 2135cn - Multifunction Color Laser Printer - Page 136


3. Open the front cover by pushing the side button and remove the jammed paper. Then, confirm that there are no scraps of paper remaining inside the
printer.

4. Close the front cover.

5. Insert the tray back into the printer, and push until it stops.
Clearing Paper Jams From the Tray 1

1. Pull the tray out of the printer carefully. Hold the tray with both hands, lift the front slightly, and remove it from the printer.

2. Remove all the jammed and/or creased paper from the tray.
NOTICE: Protect the drums of the Print Head Device (PHD) against bright light. If the front cover remains open for more than three minutes, print quality
may deteriorate.
NOTE: To resolve the error displayed on the operator panel, you must clear all print media from the print media path.
